Proel · Recording Gear

Compact 6-Channel Mixer

Item MQ6 · Designed in Italy

Final Stock

An ultra-compact 6-channel mixer that brings the clean, accurate sound of professional consoles to small setups.

Where to Buy

Find a local dealer to try it in person
Dealer? Sign in to see your cost and order. School, worship or facility? Request a quote.

Details

About this product.

Features

The MQ6 is one of the two smallest models in the series. It delivers the clean, accurate sound of a professional console in an ultra-compact format.

The MQ family

PROEL designed the MQ Series to offer high input density, a full feature set and superior audio quality in a compact, stylish package. The series includes 5 models with 6, 10, 12 and 16 inputs, covering most sound reinforcement needs.

MQ mixers are designed and engineered in Italy by PROEL R&D. Ultra-rugged cases make them durable enough for stage use. Padded carrying bags and 19" rack-mount brackets are optional for selected models.

Specifications

The details that matter.

Manuals & Downloads

Mono Input Channel

Mic Input
sensitivity · from -10 to -50 dB · Balanced XLR-F
impedance
2 kΩ
Line Input
sensitivity · from +20 to -20 dB · Balanced JACK
impedance
10 kΩ
Lo cut
75Hz, 18dB/oct.
EQ
HIGH (shelving) · ±15 dB @ 12 kHz
LOW (shelving)
±15 dB @ 80Hz

Stereo Input Channel

Line Input
sensitivity · -10 dB · Balanced JACK
impedance
10 kΩ

Master Section

Main Mix
nom. out level · +4 dBu · Balanced JACK and XLR-M
Headphones
min. impedance · 32 ohm
max. out level
(2x) 193 mW · Stereo JACK

General Specifications

Maximum level
all outputs · +22 dBu
Crosstalk
meas. at 1 kHz · > 82 dBu
HUM & Noise
unweighted · < -93 dBu
THD + Noise
at +4dB, 1kHz · < 0.008 %
Dimensions (WxHxD)
6.4 × 8.3 × 2 in (162 x 210 x 51 mm)
Weight
2.2 lb (1.00 kg)

Power Requirements

Supply
18 VAC 1000 mA - use only supplied AC/AC ADAPTER
Mains Supply Voltage
110-120 VAC (±10%) 50 / 60 Hz (US plug)
230-240 VAC (±10%) 50 / 60 Hz (EU plug)
240 VAC (±10%) 50 / 60 Hz (UK plug)
Consumption
34 W

Warranty

Standard
2 years from the date of purchase at an authorized Proel North America dealer
Extended
2 more years (4 in total) when registered on proel.com within 6 months of purchase
Details
Terms, registration links and claims: proelnorthamerica.com/pages/support
