10" 150W Studio Subwoofer

Item EK10SW

EK NF is the ideal nearfield monitor solution for any kind of music production applications. From the carefully selected transducers to the proprietary enhanced waveguides and to the low resonance cabinet design, everything has been tailored to offer the best accuracy over the whole audio...

Where to buy

Sold through authorized Proel North America dealers in the USA and Canada.

Dealer? Sign in to see your cost and order. School, worship or facility? Request a quote.

Details

About this product.

EK NF is the ideal nearfield monitor solution for any kind of music production applications. From the carefully selected transducers to the proprietary enhanced waveguides and to the low resonance cabinet design, everything has been tailored to offer the best accuracy over the whole audio spectrum. The perfectly optimized electronics, including high headroom separate Class AB amplifiers for high and low section, high precision crossover networks and separate LIMITER circuits, provide maximum resolution and minimum listening fatigue.

  • Active vented sub-woofer
  • Long-excursion 10” woofer with PP cone featuring very extended response
  • Precisely calculated front tuning port for greater low-frequency extension
  • Stereo balanced inputs, outputs and link connectors for MONO and STEREO operation
  • Optimized crossover design with HI-CUT and LO-CUT frequency control
  • High-headroom Class AB 150W amplifier with accurate CLIP LIMITER

Specifications

The details that matter.

Manuals & downloads

System type
Vented sub-woofer
Low Frequency Device
10” woofer with PP cone
LF Amplifier Continuous Power
150W Class AB
Processing
Analog
Frequency Response
40 Hz - 150 Hz
Max SPL
110 dB
Connectors
1/4” JACK, XLR-F (stereo INPUT), XLR-M (stereo OUTPUT), XLR-M (LINK)
Controls
LEVEL, HI-CUT & LO-CUT frequency selector, PHASE
Construction
Vinyl laminated MDF cabinet with MDF front
Cabinet Colour
Black
Power Supply
230 VAC or 120 VAC 50/60 Hz with LINE VOLTAGE selector
Dimensions (W x H x D)
13 x 14.4 x 14.4 in (330 x 365 x 365 mm)
Weight
33.7 lb (15.3 kg)

Warranty

Standard
2 years from the date of purchase at an authorized Proel North America dealer
Extended
2 more years (4 in total) when registered on proel.com within 6 months of purchase
