• Axiom AX12LFWH white finish (rendering; actual product and color may vary)

Axiom · Stage Equipment

12 x 3.5", Passive, Low-Frequency, High-Power, Portable Line Array Element (White)

Item AX12LFWH · Made in Italy

A passive low-frequency line array element with twelve 3.5-inch long-excursion drivers that extends AX12C and AX6C systems down to 90 Hz (white).

Where to Buy

Axiom systems are specified, sold and installed by authorized integrators and installers in the USA and Canada.

Request a System Quote
Find an integrator or installer near you
Dealer? Sign in to see your cost and order.

Details

About this product.

The AX12LF adds one octave of low-frequency extension to the AX12C and AX6C. Use it where a subwoofer is not needed, such as speech and corporate events. It shares their lightweight aluminum frame and suspension system for seamless integration.

The system

The AX12LF combines with the AX12C or AX6C in many configurations. Two AX6C equal one AX12C.

A simple setup is a two-unit column of one AX12C and one AX12LF, flown or ground-stacked. Four-unit columns can have an AX12LF at the base or at both ends. Large flown systems can use four AX12C with two AX12LF behind them in end-fire configuration.

Power the AX12LF with QC Series Class D processed amplifiers. CORE DSP presets cover the different combinations and can be controlled remotely with PRONET AX software.

Key features

  • High-power passive portable line array element
  • 12 x 3.5" long-excursion neodymium transducers with waterproof cones
  • 320 W continuous, 640 W program power
  • 90 to 200 Hz low-frequency extension for AX12C and AX6C systems
  • Transmission line back loading
  • Fast integrated suspension system
  • Aluminum frame
  • For mobile and installed systems
  • Black or white finish

Applications

  • Installed systems for theaters, houses of worship and conference rooms
  • Portable AV for corporate events

Product image is a rendering of the white finish. Actual product and color may vary.

Specifications

The details that matter.

Manuals & Downloads

System

System’s Acoustic Principle
Line Array Element
Short Transmission Line Back Loading
Acoustic Diffractor
Frequency Response (-6dB)
90 Hz - 200 Hz (Processed)
Nominal Impedance
8 Ohm
Horizontal Coverage Angle
360°
Sensitivity (2.83V)
99 dB SPL @ 3.3 ft (1m)*
Maximum (peak) SPL
124 dB SPL @ 3.3 ft (1m)*

Transducers

Type
12 x 3.5" (88mm) Neodymium magnet woofers, 1"(25mm) VC
Cone
Waterproof Cone
Voice Coil Type
Ventilated voice coil

Input Connections

Connector Type
Neutrik® Speakon® NL4 x 2 (1+/1- signal IN & LINK ; 2+/2- thru)

Power Handling

Continuous AES Pink Noise Power
320 W
Program Power
640 W

Enclosure & Construction

Width
4.2 in (107 mm)
Height
45.9 in (1166 mm) (without flying system)
47.7 in (1212 mm) (with flying system)
Depth
7.6 in (193 mm)
Enclosure Material
Aluminum
Paint
High resistance, water based paint
Flying system
Aluminum Fast Link structure with dedicated pins
Net Weight
29.1 lb (13.2 kg) (without flying system)
33.7 lb (15.3 kg) (with flying system)
*measured @13.1 ft (4 m) and scaled @3.3 ft (1 m)

Warranty

Standard
2 years from the date of purchase at an authorized Proel North America dealer
Details
Terms, registration links and claims: proelnorthamerica.com/pages/support
