Passive 2-Way 8" Loudspeaker System
A passive 2-way 8-inch installation loudspeaker with 320 W peak handling, 90 x 90-degree coverage and a black plywood cabinet.
Where to Buy
Find a local dealer to try it in person
Details
About this product.
Sound and coverage
The LTX8P pairs an 8" woofer with a 1.5" voice coil and a 1" compression driver. A symmetrical 90° x 90° horn gives even coverage, and response runs from 70 Hz to 20 kHz.
It handles 160 W continuous and 320 W peak at 8 ohms, with 92 dB sensitivity (1 W/1 m). Two SPEAKON connectors allow easy linking.
Cabinet and mounting
The light plywood cabinet has a scratch-resistant finish and a foam-backed steel grille. The KPTLTP tilt-and-swivel bracket mounts it on walls or ceilings, and a pole socket allows floor-stand use.
Specifications
The details that matter.
- System type
- 2-way vented enclosure
- High Frequency Device
- 1" compression driver with 1" VC
- Low Frequency Device
- 8" woofer with 1.5" VC
- Angular Coverage
- 90° H x 90° V
- Power Rating Continuous
- 160 W
- Power Rating Peak
- 320 W
- Impedance
- 8 ohm
- Frequency Response
- 70 Hz - 20 kHz
- SPL (1 W / 1 m)
- 92 dB
- Connectors
- 2 x SPEAKON
- Flying System
- 3 x M8 (top/side), 3 x M6 (rear)
- Construction
- Plywood
- Cabinet Color
- Black
- Handles
- 1 x rear
- Mounting Pole
- 1 x bottom
- Mounting Bracket
- KPTLTP tilt and swivel bracket
- Dimensions (W x H x D)
- 8.9 × 17.4 × 8.7 in (227 x 442 x 220 mm)
- Weight
- 15.3 lb (6.95 kg)
-
