6 x 3.5" Passive Portable Line Array Element (White)
A passive portable line array element with six 3.5-inch neodymium drivers for front-fill, under-balcony, stage monitor and multi-column systems (white).
Where to Buy
Axiom systems are specified, sold and installed by authorized integrators and installers in the USA and Canada.
Find an integrator or installer near you
Details
About this product.
Overview
Six 3.5" neodymium transducers with waterproof cones suit portable and installed systems that need high power and clarity. The aluminum frame keeps the box light and strong.
A back-loaded transmission line gives clean mid-bass and natural cardioid behavior. The Front Diffraction Waveguide (FDW) delivers wide horizontal dispersion for many applications.
The system
Use the AX6C alone or in multiple columns for fixed installs, front-fill, under-balcony and low-profile stage monitoring. It also combines with AX12C and AX12LF columns in many configurations.
Drive it from the SW2100A processed active subwoofer or QC Series Class D processed amplifiers. One channel drives up to eight AX6C modules, or a mix of AX6C and AX12C.
CORE DSP presets cover the different combinations and can be controlled remotely with PRONET AX software.
Rigging and accessories
The AX6C is easy to transport, and its integrated suspension system makes setup fast. Each unit comes with two aluminum brackets and four pins to join it to other AX6C, AX12C or the SW2100A. The brackets offer 0° and 2° inter-cabinet angles.
- KPTAX12C flybar for suspending up to 8 units
- KPTWAX6C bracket for wall, ceiling or floor mounting
- KPTWAX12C wall bracket for up to 4 units
- KPTFAXC foam adapters for stage monitor or front-fill use
- KPTFAX12C floor stand
- KPTPOLEAX12C pole adapter
- AXCASE12PT flight case for six AX6C
- COVERAX6C cover and carry bag for one AX6C
- PLG716 galvanized steel shackle
- ESO2500LU025 25 cm 4 x 4 mm speakON linking cable
Features and applications
- High-power passive portable line array element
- 180 W continuous, 360 W program power
- Transmission line back loading for clean mid-bass and natural cardioid behavior
- Wide horizontal dispersion from the Front Diffraction Waveguide
- Fast integrated suspension system
- Black or white finish
- Portable systems for live bands and mobile DJs
- Installed systems for theaters, clubs, houses of worship and conference rooms
- Portable AV for corporate events
Specifications
The details that matter.
System
- System’s Acoustic Principle
- Line Array Element
- Short Transmission Line Back Loading
- Acoustic Diffractor
- Frequency Response (-6dB)
- 200 Hz - 16 kHz (Processed)
- Nominal Impedance
- 32 Ohm
- Horizontal Coverage Angle
- 100°
- Sensitivity (5.66 V)
- 102 dB SPL @ 3.3 ft (1m)*
- Maximum (peak) SPL
- 124 dB SPL @ 3.3 ft (1m)*
Transducers
- Type
- 6 x 3.5" (88mm) Neodymium magnet woofers, 1"(25mm) VC
- Cone
- Waterproof Cone
- Voice Coil Type
- Ventilated voice coil
Input Connections
- Connector Type
- Neutrik® Speakon® NL4 x 2 (1+/1- signal IN & LINK ; 2+/2- thru)
Power Handling
- Continuous AES Pink Noise Power
- 180 W
- Program Power
- 360 W
Enclosure & Construction
- Width
- 4.2 in (107 mm)
- Height
- 24.6 in (626 mm) (without flying system)
- 26.5 in (673 mm) (with flying system)
- Depth
- 7.6 in (193 mm)
- Enclosure Material
- Aluminum
- Paint
- High resistance, water based paint
- Flying system
- Aluminum Fast Link structure with dedicated pins
- Net Weight
- 14.6 lb (6.6 kg) (without flying system)
- 19.2 lb (8.7 kg) (with flying system)
- *measured @13.1 ft (4 m) and scaled @3.3 ft (1 m)
Warranty
- Standard
- 2 years from the date of purchase at an authorized Proel North America dealer
- Details
- Terms, registration links and claims: proelnorthamerica.com/pages/support
-
